Seakeeper 3 - Seakeeper Assembly

INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 3 90378 4 4 of 15
Section 1: MECHANICAL INSTALLATION
FIGURE 3 – BEAMS CLEARANCE CONSIDERATIONS
Refer to Figure 3 for recommended clearances to transverse or longitudinal beams.
Clearances aft of the Seakeeper are shown to provide access for regular scheduled
maintenance.
