INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 3 90378 4 1 of 3
Section 5: INSTALLATION CHECKLIST AND SUPPLIES
Please Complete Checklist and E-mail to customerservice@seakeeper.com
or telefax to +1.410.326.1199
5.0 Installation Checklist
Mechanical Checklist (reference Installation Manual Section 1)
 Seakeeper Foundation Installed in Hull
 Seakeeper supplied foundation bolts torqued to specification
 Clearances around Seakeeper meet specifications and no obstructions are within
the Seakeeper envelope
Electrical Checklist (reference Seakeeper Drawing 90257 & Installation Manual Section 2)
Mount Components
 Display (near helm)
Connect Seakeeper and Customer Supplied Cables
 Cable 7 (Seakeeper supplied) – Connect Cable 7 from Seakeeper 12VDC 15A
power at customer supplied connection box, or
directly to a circuit breaker.
 – Plug connector of Cable 7 into mating
connector on the Seakeeper wire harness
 Cable 6 (customer supplied) – Install lugs on both ends of customer supplied
4 AWG ground cable
 – Connect one end of Cable 6 to nearest vessel
ground and other end to Seakeeper rear brace
Connect Seakeeper Supplied Cables
 Conductors 1&2 (Seakeeper supplied) – Connect Conductors 1&2 from
Drive Box to 12 VDC 100A at customer supplied
connection box or directly to circuit breaker
 Cable 5 (Seakeeper supplied) – Connect Cable 5 from mating connector on
Seakeeper wire harness to customer supplied
12 VDC 3A seawater pump
