Figure 5.21
If data from previously tested vehicle is not erased, data from
current test will be stored in a temporary cache.
3) Use the UP/DOWN scroll button to select a memory location
and press the OK button.
Figure 5.22
The asterisk (*) icon on the screen indicates that there is a
previous recording in the memory location.
If you select a location marked with an asterisk (*) icon, a
message prompting to overwrite old recording displays.
Figure 5.23
…………….Select Memory 1/3..
Location #1 *
Location #2
Location #3 ?
…….……Pick Trigger Mode 1/2
Manual Trigger
DTC Trigger
?
Select Memory ...
A previous recording
exists! Do you want
to overwrite it?
YES NO
To Next Page
