If you wish to proceed with overwriting the old recording,
press the OK button; if you do not wish to overwrite it, use
the LEFT/RIGHT button to select NO or press the ESC
button to pick another memory location.
4) Observe on-screen instructions.
If Manual Trigger is selected, following screen shows:
Figure 5.24
If DTC Trigger is selected, following screen shows:
Figure 5.25
5) Wait for DTC to trigger recording or press OK to start recording.
(Figure 5.26)
Drive till a DTC is detected when DTC Trigger is selected. If no
DTCs are detected, press ESC to exit recording.
……………Manual Trigger……………...
Ready to record!
Press [ENTER] to
start recording…
Press [ESC] to exit
………………….DTC Trigger……………..
Waiting for DTC to
trigger recording…
Press [ESC] to exit
