2. Check state-of-charge of battery. For accurate cranking voltage
test results, the battery must be at least 75 percent charged.
3. Make sure the handbrake is on and the gear is on neutral or P for
an automatic
STARTER TEST PROCEDURE
Connect to DLC with EOBD connector.
Follow the steps to complete the test:
1. Perform PRETEST.
2. Turn off all of the vehicle's electrical accessories.
3. Connect the tool to vehicle‟s DLC with EOBD connector
4. Turn on the scan tool and wait for Main Screen to appear.
(Figure 3.1)
5. Use the UP/DOWN scroll button to select START TEST from
main screen. (Figure 3.1) The scan tool will show as below.
Figure 8.1
6. Check that the ignition is on and engine not running. Then press OK
button to continue. The scan tool will prompt you to start
engine.
