Figure 8.2
7. Start engine and begin the test. There may be five test results.
Table 1: Starter System Decisions and Recommendations
The starter voltage is normal and the starting
system is OK. (Figure 8.3)
The vehicle can’t start and there is a problem
with the starting system. Check the battery,
connection, wiring and starter. (Figure 8.4)
The starter voltage is low and you’d better
check the starter system before a problem
happens. (Figure 8.5)
The starter voltage is low and the battery is
discharged. Fully charge the battery and retest
the starter system. (Figure 8.6)
