© 2017 SeaStar Solutions i7700 Installation Supplement, Rev. B
To assist with the installation and maintenance of this Electronic Shift
and Throttle system SeaStar Solutions recommends that:
• Installation MUST be performed by a SeaStar Solutions
authorized installer.
• Read and understand ALL installation manuals before starting
the installation process. Knowing the correct order of installation
and location of components will drastically reduce installation
time as well as prevent common installation errors.
• Read and understand ALL Safety Information that is noted in this
manual and ALL other Installation Manuals.
If any problems are found before, during or after the installation of the
steering system, please contact Technical Support for assistance:
Technical Support
Web: www.seastarsolutions.com
E-mail: seastar@seastarsolutions.com
Phone: 604.248.3858
Fax: 604.279.2202
3.1 Important Information/Technical
Support Contact
3.0 INSTALLATION
Mount the control head on the dash in an area which will allow for
convenient access during use. Whenever possible, it should be
mounted in a location to minimize water spray. Ensure that the control
handle(s) can be moved throughout the complete range of motion in
both forward and reverse without interference. ABYC standard P-14
calls for a minimum of 2-1/2" (64 mm) clearance between the
control lever and the steering wheel rim under all possible lever and
wheel positions.
The control head requires one of the dash cutout templates in
Appendix A.
Control Head Trim Switch Connection (Optional)
The control head includes a single trim/tilt switch on the end of the
port handle. This switch can be wired to provide synchronous trim/
tilt control of all engines. If independent trim/tilt is desired use tilt/
trim kit HA5491 (for twin engine configurations) and connect the
wiring as shown in Figure 3-1.
3.2 Installing the Control Head
3.2.1
