Seastar Solutions i7700 Installation Manual

D-2
© 2017 SeaStar Solutions i7700 Installation Supplement, Rev. B
The current firmware version installed in a component can be checked
through Datalink.
NOTE: When opening component windows in Datalink, it is good
practice not to have more than two components open at a time to
avoid potential communication errors.
D.1 Checking Component Firmware
Revision Levels
Figure D-2. Datalink workspace.
Using DATALINK
1. Connect the computer to the i7700 system as shown in section
C.2.
2. In the ‘Interfaces’ section in Datalink, click on the
box to expand
the component information. See figure D-2. (In an i7700 system
you will see only the Control Head(s) and Actuators in the
component list.)
3. Firmware revision can be found under the ‘Firmware Part
Number’ field.
D.1.1
FIRMWARE
REVISION
DATALINK
VERSION
CLICK TO EXPAND
COMPONENT
INFORMATION
