Seatex DPS 132 Installation Manual, rev. 0 Appendix K – DGPS 465
89
Figure 20 Starting the UHF channel setting program
To set the correct frequency, correct channel number (1) must be selected. When selected,
the channel number will be highlighted. In figure 21, channel 5 is selected. Select Com 2,
9600, n, 8, 1, No. Press Set (2) when the correct settings are selected. A dialogue box will
pop up with a confirmation of the channel selection. Press OK (3) to confirm the selection.
After selection, close the program by pressing the X (4) in the right upper corner.
Figure 21 Channel setting program
FSP ref.: A11211400XRBRA0
