Seatex DPS 132 - Appendix D

Seatex DPS 132 Installation Manual, rev. 0 Appendix D - DPS setup file

57

Appendix D - DPS setup file

!------------------------------------------------------------------------------*

!- DPS SETUP FILE. *

!- *

!- This is the setup file where user configurations are entered. *

!- *

!- This is not the only place to configure DPS. Some settings are done under *

!- Windows registry and some settings are done in TXT and DEF files. These *

!- settings does not affect the operational scenario of the DPS system and *

!- are not to be changed by users or service personnel. *

!- *

!- Lines with text embraced by [ and ] are section names, used by some parsing *

!- programs for navigation within this setup file. All descriptive text about *

!- a section, i.e. comment lines (starting with ! or # characters), should be *

!- placed immediately BEFORE the section names. *

!- *

!- Generally, do NOT alter the position of the setup information in this file, *

!- just modifiy existing values or add new information within the related *

!- section. *

!- *

!------------------------------------------------------------------------------*

!--------------------------- DP INTERFACE AND DECODING ------------------------*

! A total of 9 DP Interfaces may be set up, starting at 1 *

! *

! Comm parameters: nh:no handshake, sh:software handshake, *

! hh:hardware handshake *

! Comm parameters: nh:no handshake, sh:software handshake, *

! hh:hardware handshake *

! DATUM_n Datum to use for position output (text). *

! Valid selections: WGS84, ED50, NAD27. Default is WGS84 *

! OUTPUTMODE_n 0: event-driven 1:timer-driven *

! OUTPUTINTV_n output interval between datagrams in ms *

! NMEA_OUTPUT_n Sequence of NMEA messages to send to DP *

! Messages conform with NMEA 0183 Version 2.2 unless *

! otherwise noted. *

! DPINTERFCONSOLE_n Console mode - 0: no console, 1: console, 2: Show NMEA *

! TIME_PRECISION_n Precision of time output, default 2 *

! POSITION_PRECISION_n Precision of position output, default 6 *

! *

! UTM Settings are only used when ARABB telegram is selected *

! UTM_MODE_n UTM mode: *

! 0:AUTO_EX, automatic zone calculation with extended zones *

! 1:AUTO_NOT_EX, automatic zone calculation *

! 2:MANUAL, manual zone input *

! UTM_ZONE_n UTM Zone: 1-60 (used when MANUAL UTM mode is selected) *

! UTM_ZONE_OFFSET_n UTM Zone Offset : range +/-3.0 (MANUAL UTM mode) *

! *

! Supported NMEA messages (for NMEA_OUTPUT_n) : *

! *

! NONE No output *

! ARABB Absolute position (ABB DP) *

! ABBDP Non-NMEA ABB DP telegram with Position, speed and course *

! ARTEMIS Non-NMEA ARTEMIS emulation (BCD,01 telegram) *

! CRYPT_FUG Cryptated position output *

! DPGGA NMEA UKOOA/IMCA DGPS Interfacing format. *

! WARNING: Not fully compatible with GPGGA. Systems not *

! distinguishing talker ID in the NMEA telegrams might*

! face problems with this telegram ! *

! GNS Fix data for single or combined satellite navigation *

! systems (GNSS) *
