Seatex DPS 132 Installation Manual, rev. 0 Specification
4
2.3 Environmental specification
DPS 132 Unit
Enclosure material:..................................................................................................... Aluminium
Operating temperature range:.................................................................................. +5 to +40ºC
1
Recommended operating temperature range:..........................................................+20 to +25ºC
Operating humidity: .......................................................................... Max. 95% non-condensing
Storage temperature range: ......................................................................................-20 to +60ºC
Storage humidity: ..................................................................................................Less than 55%
Vibration testing according to:..................................................................................... EN 60945
GPS Antenna
Enclosure material:..........................................................................................................Polymer
Operating temperature range:...................................................................................-40 to +70ºC
Operating humidity: ...................................................................................................Max. 100%
2.4 Radio frequencies
GPS receiver ZX-Eurocard .... 1575.42 MHz
± 10 MHz and 1227.60MHz± 10 MHz (Rx only)
IALA Beacon receiver: ................................................................. 280 kHz- 320 kHz (Rx only)
2.5 Cable specification
Coax Cable Specifications (For details see Appendix B)
Type:...................................................................................................1/2" Cellflex superflexible
Attenuation:........................................................................................ 14 dB/100 m (at 1.5 GHz)
Maximum length: ............................................................................................................... 100 m
Diameter:........................................................................................................................ 13.7 mm
Minimum bend radius: ..................................................................................32 mm, single bend
Flame retardation: ............................................. IEC 60754-1, -2, IEC 60332-1, -3.C, UL 1581,
........................................................................................................UL 1666, NEC type CATVR
1
Operating temperature up to +55ºC for 10 hours.
