Seatex DPS 132 Installation Manual, rev. 0 Appendix G – Mounting without DPS 132 cabinet
75
Appendix G – Mounting without DPS 132
cabinet
A DPS 132 system that is not delivered with cabinet shall be mounted on attachment rails in a
standard 19-inch rack. Minimum depth of the rack is 600 mm.
The rack must be resiliently mounted, otherwise the warranty will be void.
The rack should have air inlet on top and bottom or ventilation splits on the sides. The DPS
132 unit has ventilation on the sides. Foreced ventilation may be required if the cabinet
contains several electronic modules.
Screened cables are connected to the back of the unit, directly on the rear panel or on a
connector block with screen terminals. All cables connected to the unit must be screened.
Make sure that the minimum antenna cable bends are not exceeded, see Appendix B.
Keyboard and mouse are connected on the rear panel. A PS2 or serial mouse (Com2) can be
used. Make sure that the keyboard screen is connected to chassis on the DPS 132 unit.
Note The recommended keyboard cable length is 3.3 m (10 feet) maximum without
degradation. If longer keyboard cable is needed, please use keyboard extender.
CAUTION
