Seca 336 - 10 Technical Data; General Technical Data

70 •
17-10-07-649-100a/04-2018S
10.TECHNICAL DATA
10.1 General technical data
General technical data
Dimensions
•Depth
•Width
•Height
308 mm
650 mm
110 mm
Net weight
• Scale without measuring rod
• Scale with digital measuring rod
seca 234
• Scale with analog measuring rod seca 232 n
approx. 3.7 kg
approx. 5.2 kg
approx. 5 kg
Ambient conditions, operation
•Temperature
• Air pressure
•Humidity
+10 °C to +40 °C / +50 °F to 104 °F
700 - 1060 hPa
30 % - 80 %, no condensation
Ambient conditions, storage
•Temperature
• Air pressure
•Humidity
-10 °C to +65 °C / +14 °F to 149 °F
700 - 1060 hPa
0 % - 95 %, no condensation
Ambient conditions, transport
•Temperature
• Air pressure
•Humidity
-10 °C to +65 °C / +14 °F to 149 °F
700 - 1060 hPa
0 % - 95 %, no condensation
Height of digits 20 mm
Power supply
• Power supply unit (model-dependent)
- Power supply
- Maximum current consumption
• Batteries
- Power supply
-Battery type
12 V
Type 500 mA
9 V
6 x type AA, 1.5 V
USB module (model-dependent)
• Current consumption of scanner Max. 500 mA
Supply voltage 100 V - 240 V
Power supply frequency 50 Hz - 60 Hz
Current consumption
• Excluding measuring rod, excluding WiFi interface,
excluding USB interface, excluding background lighting
• Including digital measuring rod
seca 234, WiFi interface
activated, USB interface activated, permanent back-
ground lighting (brightness: 100 %)
26 mA
240 mA
Maximum runtime in battery mode
• Excluding WiFi interface, excluding USB interface,
excluding background lighting
• WiFi interface activated, USB interface activated
approx. 60 hours
power supply unit recommended
Medical device in accordance with Directive 93/42/EEC Class I with measuring function
EN 60601-1:
• Insulated device, protection class II:
• Electrical medical device, Type B:
Type of protection IP20
Duty cycle Continuous duty
