INTRODUCTION
VER.
*
.
**
.--
(Ver)
Major version
(may be two digits)
Minor version Release version
GAME VERSION NOTATION
NOTATION IN DIAGRAMS
Version numbers appearing in TEST MODE are indicated by the asterisks below. When describing software version
upgrades, only major version and minor version numbers are shown. Release version numbers are for SEGA's
administrative use only. If you require these numbers, contact the ofce listed in this manual.
Information regarding fasteners (screws, nuts, washers, etc.) and connectors is shown in the diagrams in this manual
as follows.
NOTATION USED IN THIS MANUAL
Tag description
(only shown if connector has a tag)
Connector color
(only shown if color other than white)
Large at washer
Surface treatment
SCREW (1), black
M4 x 8, w/at & spring washers, large at washer used
Screw specication
Means that the washer must
be attached to the screw.
Means that the washers are
integrated into the screw.
Integrated washers
Spring washer
Flat washer
CONNECTOR (3)
Type or manufacturer name
XA3P red [SATL] (2), YL6P
Number of connector pins
13B4e
