48
GAME TEST MODE
OUTPUT TEST
COIN LOCK OUT OFF
LEFT PARTITION LED RED OFF
LEFT PARTITION LED GREEN OFF
LEFT PARTITION LED BLUE OFF
RIGHT PARTITION LED RED OFF
RIGHT PARTITION LED GREEN OFF
RIGHT PARTITION LED BLUE OFF
BUTTON LED TRIANGLE OFF
BUTTON LED SQUARE OFF
BUTTON LED CROSS OFF
BUTTON LED CIRCLE OFF
TOUCH SLIDER LED RED OFF
TOUCH SLIDER LED GREEN OFF
TOUCH SLIDER LED BLUE OFF
-> EXIT
SELECT WITH SERVICE BUTTON AND PRESS TEST BUTTON
4-4 OUTPUT TEST
View the status of output devices. Use this screen to perform periodic checks on output devices.
OUTPUT TEST screen
CONTROLS
- Press the SERVICE Button to select menu item.
- When the TEST Button is pressed, the selected item changes from OFF to ON and the corresponding output
devices either light up or operate. When the TEST Button is pressed again for menu items that are ON, they will
change from ON to OFF and either go dark or cease to operate.
Operations can also be performed using the following input method.
×
Moves the arrow downward
□
Moves the arrow upward
L, R,
○
,
△
Adjust the value for the selected item.
- Select EXIT and press the TEST Button to return to the GAME TEST MENU screen.
3
4
