EXPLANATION OF TEST AND DATA DISPLAY
2
The adjustment method is explained below.
TOP adjustment
Select TOP, aim at the top mark, and pull the trigger. The new value will
appear in the NEW column. The previous value will be shown in the OLD
column.
LEFT adjustment
Select LEFT, aim at the left side mark, and pull the trigger. The new value
will appear in the NEW column. The previous value will be shown in the
OLD column.
CENTER adjustment
Select CENTER, aim at the center mark, and pull the trigger. The new values
for X and Y will appear in the NEW column. The previous X and Y values
will be shown in the OLD column.
RIGHT adjustment
Select RIGHT, aim at the right side mark, and pull the trigger. The new value
will appear in the NEW column. The previous value will be shown in the
OLD column.
BOTTOM adjustment
Select BOTTOM, aim at the bottom mark, and pull the trigger. The new
value will appear in the NEW column. The previous value will be shown in
the OLD column.
3
Use the CHECK option to check the detection position.
4
When all checks are completed, press the TEST Button. The GAME TEST MODE screen reappears after
saving the setting data.
