GAME BOARD (LINDBERGH RED EX)
The LINDBERGH RED EX is inside the front door of the cabinet on the left side when facing the screen. Remove
the entire wooden board (ASSY MAIN BD) on which the LINDBURGH RED EX is placed.
17-1 FIG. 01 17-1 FIG. 02
17-1 FIG. 04
CORD CLAMP
Detach connectors
D-SUB15P,
JVS CONNECTORS
Detach connectors
SM4P, SM8P, YL3P
11-1 REMOVING THE LINDBERGH RED EX
1
Turn the power off.
2
Unlock the back door with the master key, and take it off.
3
Release the cord clamps.
4
Detach the 5 connectors.
