Seko KOMPACT DPT - Frequency Signal Input Modes; Dry Contact Frequency Input; Hall Sensor Frequency Input; Voltage Signal Frequency Input

EM00136299 rev. 1.0 IT
2
Dip switch position and connections for frequency signals input mode
4
5
6
Frequency input Ground
Signal
+12Vdc
4
5
6
Frequency input
Ground
Signal
+12Vdc
4
5
6
Frequency input Ground
Signal
+12Vdc
Connection diagram for frequency input
with dry contact
Connection diagram for frequency input
with Hall sensor.
Connection diagram for frequency input
with voltage signal
Dip switch position = Position ON
Dip switch position = Position ON
Dip switch position = Position 1
10K
R14
100n
C28
FREQUENCY
470R
R17
MMBT2222
Q1
BAV99
D6
10K
R13
10K
R19
VCC
GND_C
VDD
1
2
3
4
5
6
MORS 6P M 3.81 V
T1
1 2
SW1
