3. Screen Operation
Item List
No. Part Name Description
1
Status Bar Displays the setting contents. ( P14)
2
[Measuring Mode] Icon
Displays the current Measuring Mode. (
P22)
Touch the icon to switch to the Measuring Mode Selection
screen.
3
[Target] Indication
Displays the target color temperature. (
P26)
Touch the icon to switch to the Target Color Temperature
Input screen.
4
[Display Mode] Icon
Displays the current Display Mode. (
P30)
Touch the icon to switch to the Display Mode Selection
screen.
5 ~ 9
[Display Item] Indication
Touch the icon to switch to the Display Item Selection
screen. (
P28)
10
[Tool Box] Icon Switches to the Tool Box screen. ( P103)
11
[Delta] Icon
(in Ambient Light Mode
only)
Displayed when comparison measurement
can be performed.
When there is no reference measurement
value, the icon is disabled.
When comparison measurement cannot be
performed, the (
) icon is not displayed.
When
is touched, the displayed measurement
is memorized and Comparison Function is activated.
When holding the Measuring Button
, the value
and the current reading will be displayed. When the
Measuring Button
is released, the display will revert to
the reference values)
When
is touched, the icon returns to
and the last measured values are displayed.
Comparison Function is cancelled when the power is
turned OFF.
Note Caution: When the Comparison Function icon is
displayed, the Memory Button
is disabled.
is displayed.
Under: Displayed if value is lower than measurement range (too dark) or color
temperature value is too low.
Over: Displayed if value is higher than measurement range (too bright) or color
temperature value is too high.
