Sekonic C-800 User Manual

32
4. Basic Operations
Operation
1.
Menu Button on the meter.
P30
Display modes from No.1 to 11 are for measurement.
Display mode No.12 is for settings.
2.
3.
Press the Measuring Button to measure.
The Light Selection Ring should be set to L ( )
when taking ambient light measurements.
( )
or Range H
( ) depending on the brightness of
P100 P102)
Receptor directly at light source during reading.
Measurements and display will take longer in light levels below 30lx. The
LCD illumination will normally switch off during measurements to avoid
Light Selection Ring
Measuring Button
Light
Receptor
Selection Screen
Measuring Screen
Touch the
[Text] icon

Sekonic C-800 Specifications

General

Dimensions (WxDxH)	73 x 183 x 27 mm
Interface	USB 2.0
USB powered	Yes

Weight and Dimensions

Weight	230 g
