www.selbit.pl
- 24 -
EMC Approval
Controller ISP-010 is approved and fulfil all requirements concerning electromagnetic
norms according to EMC. The controller ISP-010 should be set up and installed according to
European and domestic norms. Responsible for adjusting the controller is person who set up
the electric and control system on the sawing frame machine. It needs to be under EMC
regulations. The controller need to be concern as a component of the sawing frame machine,
it is not a separate machine or electronic device according to European directive (machine
directive and electromagnetic compatibility directive).
The assembler of the controller ISP-010 is responsible for fulfil all those directives. Product
and equipment described within this instruction can be modify as from technical as
operational point of view. This written description – handbook manual can not be consider as
a contract.
CHAPTER 12
Possible errors and solutions
1 Controller after turning on is not working.
Action:
- Check the Power transformer connection
2 During manual controlling – is displayed
Action:
- provide correct saw head height from main track (ch.3 p4)
3 Cutting dimensions divergence
Action:
- make auto-calibration (ch.3 p.3)
- check saw trace value (ch. 3 p.2)
4 Controller doesn’t stop the head saw or position the head saw incorrect
Action:
- check and eventually correct input divider value (ch. 3 p.1)
- check and eventually correct saw trace value (ch. 3 p.2)
- make auto-calibration (ch. 3 p. 3)
-
5 During automatic movements controller turns the feeding down and displays:
