29
8 TECHNICAL SPECIFICATIONS
GENESIS 2000 GENESIS 2000 RC
Power supply voltage U1 (50/60Hz) 3x400Vac ±15% 3x400Vac ±15%
Zmax (@PCC)
* - -
Slow blow line fuse 10A 10A
Communication bus DIGITAL DIGITAL
Maximum input power (kVA) 9.7kVA 9.7kVA
Maximum input power (kW) 6.5kW 6.5kW
Power factor PF 0.7 0.7
Efficiency (μ) 85% 85%
Cos
0.99 0.99
Max. input current I1max 14A 14A
Effective current I1eff 8.3A 8.3A
Duty factor (40°C)
(x=35%) 200A 200A
(x=60%) 170A 170A
(x=100%) 150A 150A
Duty factor (25°C)
(x=60%) 200A 200A
(x=100%) 160A 160A
Adjustment range I2 3-200A 3-200A
MMA open circuit voltage Uo 70Vdc 70Vdc
TIG open circuit voltage Uo 60Vdc 60Vdc
IP Protection rating IP23S IP23S
Insulation class H H
Manufacturing Standards EN 60974-1 EN 60974-1
EN 60974-10 EN 60974-10
Dimensions (lxdxh) 410x150x330 mm 410x150x330 mm
Weight 11.3 kg. 11.3 kg.
Power supply cable 4x2.5 mm2 4x2.5 mm2
Length of power supply cable 5 m 5 m
* This equipment complies with EN/IEC 61000-3-11.
* This equipment does not comply with EN/IEC 61000-3-12. If it is connected to a public low voltage system, it is the responsibility of the
installer or user of the equipment to ensure, by consultation with the distribution network operator if necessary, that the equipment may be
connected. (Consult the “Electromagnetic fields & interferences” - " EMC equipment classification in accordance with EN/IEC 60974-10" section).
