36
Software current
limit exceeded
Please refer to the description of function code
P8-36, P8-37.
37
Frequency lower
limit reached
(having output
at stop)
38
Alarm output
When the inverter fails and the fault handling mode is
continued, the ON signal is output.
39
Motor overheat
warning
When the motor temperature reaches P9-58, the
output ON signal
40
Current running
time reached
When the inverter runs for longer than P8-53, it
outputs ON signal.
Setting
value
Function Instruction
When the running frequency reaches the lower limit
frequency, the ON signal is output.
This signal is also ON during the stop state.
P5-06
Y2 pulse output function selection
Default: 0 running frequency
P5-07
AO output function selection
Default: 0 running frequency
P5-08
AO2 output function selection (extension)
Default: 1 set frequency
The Y2 terminal output pulse frequency range is 0.01 kHz ~ P5-09
(between 0.01 and 100.00 kHz).
The analog output AO1 and AO2 output range is 0V ~ 10V, or 0mA ~
20mA. The range of pulse output or analog output, and the calibration
relationship of the corresponding function are shown in the following table：
Set
value
Function
Function corresponding to pulse or
analog output 0.0%~100.0%
0
Running frequency 0 to the maximum output frequency
1
Set frequency 0 to the maximum output frequency
2
Output current
0 to 2 times the rated current of the motor
3
Output torque
0 to 2 times rated motor torque
4
Output Power
0 to 2 times rated power
5
Output voltage 0 to 1.2 times the rated voltage of the inverter
6
PULSE input
0.01kHz〜100.00kHz
7
AI1
0V〜10V
8
AI2
0V〜10V（or 0〜20mA）
Set
value
Function
Function corresponding to pulse or
Analog output 0.0%~100.0%
9 AI3 0V〜10V
10
Length
0 to the maximum set length
11
Count value
0 to the maximum count value
12
Communication
setting
0.0% to 100.0%
13
Motor rotational
speed
0 to the maximum output frequency corresponding
to the speed
14
Output current
Output current 55KW and below 100% corresponds
to 100.0A, 75KW and above 100% corresponds to
1000.0A
15
Output voltage
(actual value)
(100% of the output voltage corresponds to 1000.0V)
actually (1000.0V corresponds to 100% of the
bus voltage)
P5-09
Y2 pulse output
Maximum frequency
0.01kHz〜100.00kHz Default：50.00kHz
When the Y2 terminal is selected as the pulse output, the function code is
used to select the Maximum frequency value of the output pulse.
AO zero offset coefficient
-100.0%〜+100.0%
Default：0.0%
AO gain
-10.00〜+10.00
Default：1.00
Extended AO2 zero
offset coefficient
-100.0%〜+100.0%
Default：0.0%
Extended AO2 gain
-10.00〜+10.00
Default：1.00
P5-10
P5-11
P5-12
P5-13
The above function code is used to correct the zero drift of the analog
output and the deviation of the output amplitude. It can also be used to
customize the required AO output curve. If the zero offset is represented by
"b", the gain is represented by k, the actual output is represented by Y, and
the standard output is represented by X, the actual output is: Y = kX + b.
Among them, the zero offset coefficient of AO1 and AO2 corresponds to 10V
(or 20mA), and the standard output refers to the output of 0V~10V (or
0mA~20mA) corresponding to the analog output without zero offset and gain
correction.
