133
P9-21
Third fault output
terminal status
The status of all output terminals in the most
recent fault, in the order:
Y3
Y1 REL2 REL1 Y2
When the output terminal is ON, its correspon-
ding secondary position is 1, & OFF is 0. The
status of all outputs is converted to decimal
display.
P9-22
Inverter status at
the third fault
P9-23
Power-on time
during the third
fault
The current power-on time at the last fault
P9-24
Run time at the
third fault
The current running time of the most
recent failure
P9-27
Frequency at the
second failure
Same as P9-17〜P9-24
Current at the
second fault
Bus voltage at the
second fault
Second fault input
terminal status
Second fault output
terminal status
Inverter status at
the second fault
Power-on time during
the second fault
Run time at the
second fault
Frequency at the
first failure
Same as P9-17〜P9-24
Current at the
first fault
Bus voltage at
the first fault
First fault input
terminal status
First fault output
terminal status
Inverter status at
the first fault
Power-on time at
the first failure
Run time at the
first failure
Fault protection
action
selection 1
Default:00000
Fault protection
action
selection 3
BIT4
BIT3
BIT2 BIT1
BIT0
–
P9-28
P9-29
P9-30
P9-31
P9-32
P9-33
P9-34
P9-37
P9-38
P9-39
P9-40
P9-41
P9-42
P9-43
P9-44
Same as P9-17〜P9-24
P9-47
Ones place: Motor overload (Err11)
0: Free stop
1: Stop by stop mode
2: continue to run
Tens place: input phase loss (Err12)
as above
Hundreds place: output phase loss
(Err13) as above
Thousands place: external fault
(Err15) as above
Ten thousand: communication
abnormality (Err16) is the same
as above
P9-48
Default:00000
Ones place: Encoder/PG card
exception (Err20)
0: Free stop
1: Stop by stop mode
2: continue to run
Tens place: function code read and
write exception (Err21)
0: Free stop
1: Stop by stop mode
Thousands place: Motor overheating
(Err25) with P9-47
Ten thousand: Run time arrives
(Err26) with P9-47
Fault protection
action
selection 2
P9-49
Default:00000
Ones place : Custom Fault 1 (Err27)
Same as P9-47
Tens place : Custom Fault 2 (Err28)
Same as P9-47
Hundreds place : Power-on time
arrives (Err29) with P9-47
Thousands place : Drop (Err30)
0: Free parking
1: slow down parking
2:Deceleration to 7% of the rated
frequency, automatically return to
the set frequency when no load is
lost
Ten Thousand: PID feedback loss
(Err31) with P9-47
