Selec ATSEL FD300 User Manual

User Manual
148
User Manual
149
PC-18
0th run time
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
PC-19
The 0th section Acc.
and dec. time selection
0〜3
Default：0
First run time
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
0〜3
Default：0
PC-22
2nd run time
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
PC-23
0〜3
Default：0
Run time of paragraph 6
Run time of paragraph 7
8th run time
9th run time
Run time of paragraph 10
0〜3
Default：0
Run time in paragraph 12
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
Multi-segment
instruction 0 given
mode
PC-20
PC-21
The 1st stage Acc.
and dec. time selection
The 2nd stage Acc.
and dec. time selection
PC-24
PC-26
PC-28
PC-30
3rd run time
stage 4 run time
5th run time
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
Default：0.0s(h)
Default：0.0s(h)
Default：0.0s(h)
PC-25
PC-27
PC-29
PC-31
0〜3
0〜3
0〜3
0〜3
Default：0
Default：0
Default：0
Default：0
The 3rd stage Acc.
and dec. time selection
Section 4 Acc.
and dec. time selection
Section 6 Acc.
and dec. time selection
PC-32
PC-34
PC-36
PC-38
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
Default：0.0s(h)
Default：0.0s(h)
Default：0.0s(h)
PC-33
PC-35
PC-37
PC-39
0〜3
0〜3
0〜3
0〜3
Default：0
Default：0
Default：0
Default：0
Section 7 Acc.
and dec. time selection
Section 8 Acc.
and dec. time selection
The 9th paragraph Acc.
and dec. time selection
Section 10 Acc.
and dec. time selection
Section 5 Acc.
and dec. time selection
PC-40
Run time of paragraph 11
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
PC-41
The 11th paragraph Acc.
and dec. time selection
PC-42
0〜3
0〜3
0〜3
Default：0
Default：0
Default：0
Run time in paragraph 13
Run time in paragraph 14
Run time in paragraph 15
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
0.0s（h）〜6553.5s（h）
Default：0.0s(h)
Default：0.0s(h)
Default：0.0s(h)
PC-43
PC-45
PC-47
The 12th paragraph Acc.
and dec. time selection
The 13th paragraph Acc.
and dec. time selection
The 14th paragraph Acc.
and dec. time selection
PC-44
PC-46
PC-48
0〜3
Default：0
Default：0
PC-49
PC-51
The 15th paragraph Acc.
and dec. time selection
PC-50
Simple PLC runtime
unit
0: s (seconds) 1: h (hours)
Default：0
0: Given by PC-00
1: Given by AI1
2: AI2 given
3: panel potentiometer
4: PULSE
5: PID given
6: P0-08 can be modified
by UP/DOWN
This parameter determines the given channel of the multi-segment
instruction 0.
In addition to the PC-00, the multi-segment instruction 0 has a variety of
other options to facilitate switching between multiple short instructions and
other given modes. When a multi-segment command is used as a frequency
source or a simple PLC as a frequency source, switching between the two
frequency sources can be easily realized.
