Sena SRL-EXT User Manual

SRL-EXT Motorcycle Mesh & Bluetooth
®
Communication System for Shoei Helmets | 12
2 INSTALLING THE HEADSET ON YOUR HELMET
2. Insert the clamp’s back plate into the clamp insertion position. Then,
remove the clamp guide sheet.
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD
Clamp Insertion Position
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD
3. Clean the area on the left side of your helmet where you will attach
the double sided adhesive tapes with moistened towel and dry
thoroughly.
4. Peel off the double sided adhesive tape to the back of the main unit.
5. Attach the main unit to the clamp, and attach the back of the main
unit to the left side of the helmet with double-sided adhesive tape.
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD
Note: Make sure that the main unit is firmly attached to the helmet.
Maximum adhesion occurs after 24 hours.
6. Tighten the two screws until the main unit is firmly fastened to the
clamp.
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD

Sena SRL-EXT Specifications

General

Audio Advanced Noise Control	Yes
Audio Built-in SBC Codec	Yes
Audio Wide Volume Control	Yes
Battery Charging Time	2.5 hours
Certificates	CE, FCC, IC
Music Sharing	Yes
FM Radio	Yes
Voice Command	Yes
Operating Temperature	-10°C to 55°C
Profiles	HFP, HSP, A2DP, AVRCP
