Sena SRL-EXT User Manual

SRL-EXT Motorcycle Mesh & Bluetooth
®
Communication System for Shoei Helmets | 13
2 INSTALLING THE HEADSET ON YOUR HELMET
2.1.4 Cables Organization
1. Pull the thick cable over the inner padding tightly and align it with the
concave portion of the helmet as shown in the illustration.
EMERGENCY USE ONLY
PULL RED TAB AND REMOVE CHEEK PAD
Concave Portion
2. Secure the cables with adhesive tape while aligning them.
Note: Do not cover the snap fastener with the aligned cables. Make
sure the aligned cables are placed above the snap fastener.
3. Peel off the cover of the hook and loop fastener used for the wired
microphone to expose the adhesive tape. Then, attach the hook and
loop fastener on the inside of the helmet’s chin guard.
4. Attach the wired microphone to the hook and loop fastener for wired
microphone.

Sena SRL-EXT Specifications

General

Audio Advanced Noise Control	Yes
Audio Built-in SBC Codec	Yes
Audio Wide Volume Control	Yes
Battery Charging Time	2.5 hours
Certificates	CE, FCC, IC
Music Sharing	Yes
FM Radio	Yes
Voice Command	Yes
Operating Temperature	-10°C to 55°C
Profiles	HFP, HSP, A2DP, AVRCP
