A1.8 SWITCH DESIGNATION
Decimal Point/Line Number/ Lacquer Number/Print Header
SWITCH
POSITION
OPEN CLOSED
S1:1 1 decimal place displayed 2 decimal places displayed
S1:2 Line number not prompted for Line number prompted for.
S1:3
Lacquer number not
transmitted
Lacquer number transmitted.
S1:4 Printed Header Vewrtical Printer Header Horizontal
Number of Print Rows
S1:5 S1:6 ROWS
OPEN OPEN 1
OPEN CLOSED 2
CLOSED OPEN 3
CLOSED CLOSED 4
Enable Printout and define Baud Rate
S1:7 S1:8 FUNCTION
OPEN OPEN PRINTER OFF
OPEN CLOSED 9600 BAUD
CLOSED OPEN 1200 BAUD
CLOSED CLOSED 300 BAUD
