Sencon SI9500 - SWITCH BANK 2; Computer Transmission Baud Rate

SWITCH BANK 2
Computer Output Enable
SWITCH POSITION OPEN CLOSED
S2:1 Computer Output Off Computer Output On
s2:2 Software Handshake Off Software Handshake On
Computer Transmission Data Format
S2:3 S2:4 S2:5 FORMAT
OPEN OPEN OPEN 7 data bits - Even Parity - 2 Stop Bits
OPEN OPEN CLOSED 7 data bits - Odd Parity - 2 Stop Bits
OPEN CLOSED OPEN 7 data bits - Even Parity - 1 Stop Bits
OPEN CLOSED CLOSED 7 data bits - odd Parity - 1 Stop Bits
CLOSED OPEN OPEN 8 data bits - No Parity - 2 Stop Bits
CLOSED OPEN CLOSED 8 data bits - No Parity - 1 Stop Bits
CLOSED CLOSED OPEN 8 data bits - Even parity - 1 Stop Bits
CLOSED CLOSED CLOSED 8 data bits - Odd Parity - 1 Stop Bits
Computer Transmission Baud Rate
S2:6 S2:7 S2:8 BAUD RATE
OPEN OPEN OPEN 76800*
CLOSED OPEN OPEN 38400
OPEN CLOSED OPEN 19200
CLOSED CLOSED OPEN 9600
OPEN OPEN CLOSED 4800
CLOSED OPEN CLOSED 2400
OPEN CLOSED CLOSED 1200
CLOSED CLOSED CLOSED 300
*NOTE: Sencon do not guarantee operation at this speed.
