Sensus ACCUMAG - 2.7 Torques and pressures

10 Chapter 2: Installation
WQG-10004-01 accuMAG Meter Quick Guide Software v4.1.2
2.6.7 Open discharge
Figure 2-11: Installation before an open discharge
2.6.8 Bends
Figure 2-12: Installation in bending pipes
