3.2 Grounding
Figure 3-1: Grounding
DN25...300: grounding without grounding rings. The flow sensor is equipped with a reference
electrode.
DN350...600: apply grounding rings if required. For example in case of metal pipes with internal
coating and non-conductive pipelines.
