97Appendix E: MIDI Implementation
Sequential Prophet Rev2 User’s Guide
Appendix E: MIDI Implementation
Request Program Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 0101 Request Program Transmit
0000 00vv Bank Number, 0 - 7
0vvv vvvv Program Number, 0 - 127
1111 0111 End of Exclusive (EOX)
The Rev2 will respond by sending out the program data in the format
described below in Program Data Dump.
Request Program Edit Buffer Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 0110 Request Program Edit Buffer Transmit
1111 0111 End of Exclusive (EOX)
The Rev2 will respond by sending out the current program edit buffer in
the format described below in Program Edit Buffer Data Dump.
Request Global Parameter Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 1110 Request Global Parameter Transmit
1111 0111 End of Exclusive (EOX)
The Rev2 will respond by sending out the current values of the global
parameters in the format described in Global Parameters Data Dump.
Program Data Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 0010 Program Data
0000 00vv Bank Number: 0 - 9
0vvv vvvv Program Number: 0 - 99
0vvv vvvv 2046 bytes expanded to 2339 MIDI bytes in “packed MS bit” format
1111 0111 End of Exclusive (EOX)
Program Edit Buffer Data Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 0011 Edit Buffer Data
0vvv vvvv 2046 bytes expanded to 2339 MIDI bytes in “pa cked MS bit” format
1111 0111 End of Exclusive (EOX)
Global Parameters Data Dump
Value Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 1111 Main Parameter Data
0vvv vvvv 50 nibbles (LS then MS) for 25 Global parameters
1111 0111 End of Exclusive (EOX)
The Global Parameters Data Dump is not recognized when received. It is only
transmitted when requested. NRPN messages are used to change Globals.
