95Appendix E: MIDI Implementation
Sequential Prophet Rev2 User’s Guide
Appendix E: MIDI Implementation
NRPN Layer
A
NRPN Layer
B
Value Description
182 2230 0-4 Gated Seq. Mode
183 2231 0-1 Gated Seq. on/off
184 2232 0-52 Seq. 1 Destination
185 2233 0-53
(slew)
Seq. 2 Destination
186 2234 0-52 Seq. 3 Destination
187 2235 0-53
(slew)
Seq. 4 Destination
192-207 2240-2255 0-127 Gated Seq Track 1
Step 1-16
208-223 2256-2271 0-127 Gated Seq Track 2
Step 1-16
224-239 2272-2287 0-127 Gated Seq Track 3
Step 1-16
240-255 2288-2303 0-127 Gated Seq Track 4
Step 1-16
276-339 2324-2387 0-127 Seq Step 1-64
Note 1
340-403 2388-2451 128-255 Seq Step 1-64
Velocity 1
404-467 2452-2515 0-127 Seq Step 1-64
Note 2
468-531 2516-2579 128-255 Seq Step 1-64
Velocity 2
532-595 2580-2643 0-127 Seq Step 1-64
Note 3
596-659 2644-2707 128-255 Seq Step 1-64
Velocity 3
660-723 2708-2771 0-127 Seq Step 1-64
Note 4
724-787 2772-2835 128-255 Seq Step 1-64
Velocity 4
788-851 2836-2899 0-127 Seq Step 1-64
Note 5
852-915 2900-2963 128-255 Seq Step 1-64
Velocity 5
916-979 2964-3027 0-127 Seq Step 1-64
Note 6
980-1043 3028-3091 128-255 Seq Step 1-64
Velocity 6
Control NRPN Data
The following table lists the Rev2’s control NRPN data. It is received
and transmitted but not saved as part of a program.
NRPN Value Description
1088 0-1 Seq Play/Stop
16383 0-1 Seq Rec On/Off
SysEx Messages
Universal System Exclusive Message (Device Inquiry)
Status Description
1111 0000 System Exclusive (SysEx)
0111 1110 Non-realtime message
0vvv vvvv If MIDI channel is set to 1 - 16, 0vvvvvvv must match (unless MIDI Channel = ALL); always
responds if 0vvvvvvv = 0111 1111.
0000 0110 Inquiry Message
0000 0001 Inquiry Request
1111 0111 End of Exclusive (EOX)
The Rev2 responds with:
Status Description
1111 0000 System Exclusive (SysEx)
0111 1110 Non-realtime message
0vvv vvvv If MIDI Channel = ALL, 0vvvvvvv = 0111 1111. Otherwise 0vvvvvvv = Channel Number
0 - 15.
0000 0110 Inquiry Message
0000 0010 Inquiry Reply
0000 0001 DSI ID
0010 1111 Rev2 ID (Family LS)
0000 0001 Family MS
0000 0000 Family Member LS
0000 0000 Family Member MS
0jjj nnnn Main Software version: jjj - Minor rev; nnnn - Major rev
1111 0111 End of Exclusive (EOX)
