Sercel GRC Spy Pro User Manual

Doc No. 006-0211-00 Rev AK Page 30 of 33
All values must be taken at ambient conditions and the sensor allowed to stabilize if
moved from a hot to cold or cold to hot environment for a period of one hour to confirm
test validity.
ESP-1500
No.
Parameter
Minimum
Maximum
1
Intake Pressure
0.1 psi
40 psi
2
Discharge Pressure
NA
NA
3
Intake Temperature
Ambient Temp - 5°F
Ambient Temp + 5°F
4
Motor Temperature
Ambient Temp - 5°F
Ambient Temp + 5°F
5
*Vibration X
0 g
1.5 g
6
*Vibration Y
0 g
1.5 g
7
Water Cut
250
260
8
Line Voltage
20V
80V
10
Leakage Current
0 mA
25 mA
*While rotating the gauge, Vibration X and Y should vary from 0 g to 1.5 g.
ESP Sensors – Simpson Test Pass/Fail Criteria
All values in the table below are based on ambient conditions (70F, 14.7psia) using a Simpson
260 9V and Simpson 260 15V. The testing equipment should be checked periodically to ensure
the battery for the resistance test is at full capacity. If the sensor is above or below ambient
conditions for storage such as being kept outside in the winter or summer then the sensor must
be allowed to stabilize at room temperature (70F) for a period of one hour in order for the test
measurement to be accurate.
These are bench test values and are only valid when testing the sensor before it is connected to
the motor.
Simpson
260
ESP-1500
ESP-2500/3500
Spy Pro
9V
≥150KΩ
≥150KΩ
≥1MΩ
15V
≥1.5KΩ
≥2KΩ
≥10KΩ
