Surface Choke and Surge Protector Panel Assembly

Figure 21: Surface Choke and Surge Protector Assembly

90B2175

Figure 22: Surge Protector and Surface Choke Wiring Diagram

Surge Protector

Assembly

Surface Choke

3 Phase Fuse Assembly

Surface Interface Connection

Red – Gauge Signal

Black – Gauge Ground

Motor Wire Connection

Green – WHG (Wellhead Ground)

Phase A, B, C
