Sercel GRC Spy Pro User Manual

Doc No. 006-0211-00 Rev AK Page 29 of 33
APPENDIX 5
ESP Sensors - Pass/Fail Criteria
All values must be taken at ambient conditions and the sensor allowed to stabilize if
moved from a hot to cold or cold to hot environment for a period of one hour to confirm
test validity.
Spy Pro
No.
Parameter
Minimum
Maximum
1
Intake Pressure
5 psi
25 psi
2
*Discharge Pressure
5 psi
25 psi
3
Intake Temperature
Ambient Temp - 5°F
Ambient Temp + 5°F
4
Motor Temperature
Ambient Temp - 5°F
Ambient Temp + 5°F
5
**Vibration X
0 g
1.5 g
6
**Vibration Y
0 g
1.5 g
7
Vibration Z
0 g
1.5g
8
Water Cut
2500KΩ
4095KΩ
9
Line Voltage
20 V
80 V
11
Leakage Current
0 mA
25 mA
12
Wye Voltage
20 V
80 V
*Spy Pro 9 and 11 only
**While rotating the gauge, Vibration X and Y should vary from 0 g to 1.5 g.
ESP-2500 / 3500
No.
Parameter
Minimum
Maximum
1
Intake Pressure
0.1 psi
40 psi
2
*Discharge Pressure
0.1 psi
40 psi
3
Intake Temperature
Ambient Temp - 5°F
Ambient Temp + 5°F
4
Motor Temperature
Ambient Temp - 5°F
Ambient Temp + 5°F
5
**Vibration X
0 g
1.5 g
6
**Vibration Y
0 g
1.5 g
7
Water Cut
250
260
8
Line Voltage
20 V
80 V
10
Leakage Current
0 mA
25 mA
*ESP-3500 only
**While rotating the gauge, Vibration X and Y should vary from 0 g to 1.5 g.
