INTRODUCTION
This field installation manual will explain in detail the operation and installation of all
Sercel-GRC ESP Monitoring Systems. ESP gauge instructions are for the following
gauge models: ESP-1500, ESP-2500, ESP-3500, and Spy Pro.
ESP Downhole Gauge Pressure Measurement
The intake pressure measures the pressure inside the motor housing. Motor oil protects
the intake pressure port from well fluid contamination.
The discharge pressure measures the pressure at the pump discharge port via a
hydraulic line connection to the discharge port on the pump. This connection is available
only on Dual Pressure gauges such as the ESP-3500, and Spy Pro 9 and 11.
Surge panel and surface choke
Surface interface
For detailed surface interface instructions, refer to:
Scout-3000 Field Operation Manual PN: 006-0191-00
SPS-1500 Operation Manual PN: 006-0202-00
Data Pro Operations Manual PN: 10029355
A system installation checklist is shown in APPENDIX 3 of this manual. This checklist
will provide the installer with the ability to follow and record the installation of the
monitoring system. Please follow this guide and use the checklist provided when
installing all ESP Sensor Systems.
