Data Pro
The Data Pro is a high-performance universal configurable surface readout. The Data
Pro can operate as a simple independent RTU and/or support internal SPS-1500 or
FIC-1500 gauge interfaces. The main features are data logging, real-time graphing,
historical graphing, Modbus communication, and gauge configuration. The Data Pro can
be powered by either an AC or DC power supply and is enclosed in an NEMA-4X rated
non-conductive, rust-proof enclosure with a transparent window and side latches.
Figure 26: Data Pro Surface Interface Unit
Operating Temperature
Range
-20ºC to +60ºC
DC Operating Voltage
+12VDC (2.4A) to +24VDC (1.5A)
Capable of handling 3A of inrush current on
startup
AC Operating Voltage
100VAC Min (400mA) to 240VAC Max (200mA)
50Hz – 60Hz
NOTE: Primary current over protection must
be supplied by user to limit current to 1A.
Display
7-inch Color LCD, resolution 840 x 480
User Interface
Touch-Screen LCD
Enclosure Dimensions
12” x 10” x 5”
Enclosure Rating
NEMA-4X
Analog Inputs
3 x 0-15VDC or 0-64mA 15-bit resolution
Analog Outputs
2 x 4-20mA 12-bit resolution
Alarm/Relay Outputs
2 x DPST dry contacts
5A @ 250 VAC
5A @ 30 VDC
Modbus Ports
1 x RS-485 (Non-Isolated)
2 x RS-232 (Non-Isolated)
1 x RS-485 or RS-232 (Isolated)
USB Ports
1
Ethernet Ports
2 (Modbus TCP/IP or SFTP)
Storage Capacity
5 GB Internal
