Serpent 710 - Shock Oil Filling and Bleeding

17
Y3
3x1.5mm
Fill the shock body with shock oil, with the piston at
the bottom.
Bleeding
Let the oil settle and allow the air to escape. Slowly
move the piston up and down to release any trapped
air bubbles. Repeat as necessary until no bubbles
appear.
Use a shock rod gripping tool, or grip the shock rod
at top of exposed threads with side cutting pliers. Be
sure not to damage the shock rod.
Y3
Step 4.4
Step 4.5
Step 4.6
1
2
Lubricate O-ring with shock oil before
sliding onto shock shaft.
Hint:
Pre-thread ball-
joint with M3 screw for
easy assembly
