Serpent 710 - Page 22

22
E11
3x8mm
B12
3.5x9.5mm
Step 6.4
Step 6.5
E10
3x6mm
E11
3x8mm
R4
4mm
Step 6.6
2
3
5
4
1
4
3
2
1
1
6
5
For clockwise circuits with mostly right
hand corners the fuel tank lid nipple
should be placed on the right side of the
lid and the grubscrew on the opposite
side. The opposite is true for anti clock
-
wise tracks with mostly left hand corners.
Important!
Check that the fuel line and
pressure line are free from debris and not
blocked
Remove screws, but leave spacers
in place atop front bulkheads.
1
Correct orientation of
finished servo saver
Front
Rear
Bag 31, E11
Bag 03,
B12
Bag 04, 32,
U, E10, E11
E11
E11
H9
H9
3x4mm
B12
B12
B12
B12
U3
E10
E11
U3
5x8mm
R4
Note: The fuel tank is equipped with
a mounting point where shims can be
mounted in the tank to make the vol
-
ume exactly 75cc.
For important races always have the
volume of your fuel tank checked.
