Serpent 710 - Page 23

23
E11
3x8mm
U3
5x8mm
Step 6.7
P1
2x10mm
Step 6.9
Step 6.8
4
5
6
1
3
2
44.5mm
1:1
72mm
1:1
1
Position the metal pin at
the desired body mount
-
ing height and then press
the plastic collar down
until it clips into place.
Correct orientation of
mounted servo saver
Left and right track rods are the same length
E11
E11
U3
P1
P1
P1
P1
P1
Bag E11
Steering rod length
