Servomex SERVOPRO 4100 User Manual

B.2
Derived measurement data
Derived measurement data associated with each of the four possible transducer positions is
available in a block of input registers that can be read using Modbus function code 04.
Analogue input data
Analogue input data from the two external mA inputs is available in a block of input registers
that can be read using Modbus function code 04.
30022 – 30023 I4 Measurement Measurement 4 value in IEEE 754 floating point format
30024 – 30026 I4 Name A 6 character string containing the measurement 4 name
30027 – 30028 I4 Units A 3 character string containing the measurement 4 units
Registers Name Comments
30029 - 30030 D1 Measurement Derived measurement 1 value in IEEE 754 floating point format
30031 - 30033 D1 Name A 6 character string containing the derived measurement 1 name
30034 - 30035 D1 Units A 3 character string containing the derived measurement 1 units
30036 - 30037 D2 Measurement Derived measurement 2 value in IEEE 754 floating point format
30038 - 30040 D2 Name A 6 character string containing the derived measurement 2 name
30041 - 30042 D2 Units A 3 character string containing the derived measurement 2 units
30043 - 30044 D3 Measurement Derived measurement 3 value in IEEE 754 floating point format
30045 - 30047 D3 Name A 6 character string containing the derived measurement 3 name
30048 - 30049 D3 Units A 3 character string containing the derived measurement 3 units
30050 - 30051 D4 Measurement Derived measurement 4 value in IEEE 754 floating point format
30052 - 30054 D4 Name A 6 character string containing the derived measurement 4 name
30055 - 30056 D4 Units A 3 character string containing the derived measurement 4 units
Registers Name Comments
30057 – 30058 E1 Measurement External mA input 1 value in IEEE 754 floating point format
30059 – 30061 E1 Name A 6 character string containing the external mA input 1 name
30062 – 30063 E1 Units A 3 character string containing the external mA input 1 units
30064 – 30065 E2 Measurement External mA input 2 value in IEEE 754 floating point format
30066 – 30068 E2 Name A 6 character string containing the external mA input 2 name
30069 – 30070 E2 Units A 3 character string containing the external mA input 2 units
