2.1
SECTION 2 INSTALLATION - GENERAL
2.1 Introduction
Installation will only require the use of standard hand tools.
The analyser is suitable for indoor use and may be configured for either bench mount, panel
mount or 19" rack mount.
The analyser is rated in accordance with IEC 664 for:
'POLLUTION DEGREE 2' where normally only non-conductive pollution occurs.
'INSTALLATION CATEGORY II', which is characterised as being local level (i.e. not distribution
level), appliances and portable equipment with over-voltage impulse withstand up to
2500 Volts.
Ambient operating conditions
Select a location which allows convenient access for installation and maintenance and will
minimise ambient temperature fluctuations and vibration.
NOTE
Sections 2, 3 and 4 provide all the information required to install any 4000 series
analyser. The installer is advised to read all sections completely before commencing
installation.
Parameter Model Range
Operating temperature 4100, 4200, 4210 +5C to +40C (+41F to 104F)
4900 +5C to +45C (+41F to 113F)
Storage temperature All -20C to +60C ( -4F to +140F)
Atmospheric pressure All 79 to 124kPaa (11 to 18psia) (for
operating altitudes up to 2000m)
WARNING
• The 4000 series analyser is not suitable for use in hazardous areas.
• The analyser is not suitable for use with corrosive samples.
• Gases may be toxic or asphyxiant and must be vented to a safe
location. (In the case of the 4200 and 4210 models, gases may also be
flammable)
