PUSH ARM INSTALLATION for wing opening left
Valid also for doors opening to the right performing the same operations but opposite side.
ALWAYS mount the articulated arm from a closed door and NEVER remove the locking screw
spring preaload during the arm installation phases, the screw will be removed ONLY after having
chosen the preload to be used and performed the procedure correctly.
