Sesamo smart PRO - 7. Technical Features

7
SESAMO SMARTPRO
7. TECHNICAL FEATURES
DIMENSIONS
587x120x95mm
POWER SUPPLY
230V ±10% AC 50/60Hz
RATED POWER
85W
NIMINAL MOTOR TORQUE
35Nm
EXTERNAL DEVICES POWER
15Vdc - 12W MAX
OPENING TIME
3s ÷ 6s (70°/s ÷ 20°/s)
CLOSING TIME
4s ÷ 15s (40°/s ÷ 10°/s)
CLOSING FORCE (ACCORDING EN 1154)
EN3 ÷ EN6
MAX. OPENING ANGLE
110°
WING DIMENSION
600 ÷ 1400 mm
WEIGHT MAX. WING
See chart
WORKING TEMPERATURE
from -10°C to +55°C
ANTI-CRUSHING
Automatic traction restriction in
presence of obstacles
WEIGHT
9 kg
SERVICE
Continuos
PROTECTION
IP40
SOUND PRESSURE LEVEL (LpA)
≤70dB (A)
DEVICE EQUIPPED WITH SPRING OPENING IN THE EVENT OF LACK OF ELECTRICITY, SEE SECTIONS
WARNINGS AND INTENDED USE.
WING
(mm)
WEIGHT
(kg)
600
420
700
310
800
240
900
190
1000
150
1100
130
1200
110
1300
90
1400
80
