9
SESAMO SMARTPRO
9. ARMS
A
Slide arm: pull arm installation – for lintel depths +50mm – 100mm
B
Standard arm: push arm installation – for lintel depths max. -150mm
C
Long arm: push arm installation -for lintel depths max. -300mm
FOR A CORRECT POSITIONING PLEASE REFERS TO PARAGRAPH “ARM INSTALLATION”
