Sesamo smart PRO - 8. Dimensions and Component Identification

8
SESAMO SMARTPRO
8. DIMENSIONS AND GENERAL SPECIFICATIONS
01
Base Plate
02
Drive system (motor/gear/spring)
03
Main control board
04
Switching power supply unit
05
End cap with Internal program switch and ON/OFF switch
06
Cover
07
Battery back up (optional)
08
Kit axle extensions H=50mm (optional)
09
Kit axle extensions H=70mm (optional)
10
Kit axle extensions H=90mm (optional)
