SESAMO SMARTPRO
18. CONTROL BOARD
OUTPUT
DESCRIPTION
OUTPUT
DESCRIPTION
Connector Main-Key
(J5)
Connector Can Bus
(J8)
Connector expansion
(J21)
Connector battery recharged
card (J18)
Display + push buttons +
jumper orientation display
Connector battery back-up kit
(J19)
Connector internal sensors
(J3)
Connector selection brake
level (J11)
Dip – Switch
(S1)
Connector integrated 3
position switch
(J2)
