The SRCM has a USB port built in for the purpose of duplicating congurations
when multiple units are being setup with similar congurations. To use this func-
tion, a USB 2.0 thumb drive with 256 megabytes or larger must be used. The thumb
drive must have at least 100K or free memory available. The USB port should only
be accessed by qualied personnel.
Setra recommends the Kingston DataTraveler 112, 4GB (minimum) ash drive
along with the aid of a short mini-USB adapter cable from Tensility International
Corporation, P/N 10-00003. No PC is required.
Manufacturer Model Size (GB) Comment
Kingston DataTraveler 1 No issue
256 MB No issue
DataTraveler 4 To make Kingston work,
format as:
• Fat 32
• Must have volume label
• Do not use quick format
DataTraveler 8
DataTraveler
112
4 Passes out of the box with-
out formatting
Sandisk Cruzer 2 To make Sandisk work,
format as:
• Fat 32
• Must have volume label
• Do not use quick format
4
16
To access the USB port, rst remove the faceplate cover and set it aside. The USB
port is located on the right side of the touch-screen display driver board, and is ac-
cessed by removing the security screw and ipping up the display housing. A mini-
A MICRO USB Host Mode OTG cable (from T& S Electronics, P/N: OTG-SBK6
or from SonoXY, P/N: USB_MIC-OTG) is required to connect a standard USB 2.0
compliant thumb-drive to the SRCM USB port.
To make use of the cloning feature, rst setup one SRCM with a conguration that
represents most other SRCM units that will be used during installation. Congure
the “master” unit with all parameters needed, including alarm thresholds, condition
banners, blinking operations, I/O conguration and so on. Make sure the Save &
Exit function is used to properly save your conguration. This “master” setup will
then be downloaded to the thumb drive and for use uploading to other units.
As soon as the thumb drive is connected to the SRCM it will be recognized and
bring up a Drive Connected menu.
USB
Conguration
Cloning
To Next Page
