UO1
User Analogue Output Control 1-4
81920
0x14000
UO2
User Analogue Output Control 5-8
82176
0x14100
UF1
User I/O Fault Status and Digital Inputs
83968
0x14800
UI1
User Analogue Inputs 1-4
84224
0x14900
UI2
User Analogue Inputs 5-8
84480
0x14a00
UI3
User Analogue Inputs 9-12
84736
0x14b00
UI4
User Analogue Inputs 13-16
84992
0x14c00
Table 18 - Default I-Protocol PGN Configuration
Further details regarding the layout of signals within these messages is available from Sevcon on
request.
If a VCU is not available to generate motor control demands in I-Protocol format, TracApp can be used
instead.
